Autocad drawing EXIT sign with an arrow Emergency exit signage dwg

EXIT sign with an arrow Emergency exit signage

Autocad block : EXIT sign with an arrow Emergency exit signage

Description of this template : AutoCAD drawing of a green EXIT sign with an arrow, designed as an emergency exit symbol. This block is available in dwg and dxf formats, ready for insertion into CAD drawings. It complies with international safety standards like ISO, ensuring accuracy for architectural, engineering, and industrial design applications. Ideal for projects requiring precise emergency signage, iso 7010.
EXIT signs are crucial safety symbols used to indicate emergency exit routes. Typically green (RAL 6032) with bold EXIT text and directional arrows, they are designed to be easily recognizable in emergency situations. These signs comply with safety standards like ISO, ensuring consistent use in architectural and engineering projects worldwide,Emergency exit
